Side Shooting Light

Description

Side Shooting Light — auxiliary lighting by SYNCWILD.

LED Side Shooting Lights – 3.5 Inch, 5.5 Inch & 7 Inch Wide-Angle Off-Road Lights

Improve side visibility and overall lighting coverage with high-performance LED Side Shooting Lights designed for off-road, overland, 4x4, truck, and utility vehicle applications. Available in 3.5-inch, 5.5-inch, and 7-inch sizes, this side shooting light series is engineered with dedicated side-emitting lighting technology to provide a wider illumination angle than conventional forward-facing LED lights.

Unlike traditional driving lights that primarily project light forward, these LED Side Shooting Lights are designed to illuminate both the forward and side areas around the vehicle. The wide-angle side illumination helps improve visibility around corners, trails, obstacles, work areas, and other off-road environments where conventional forward lighting may leave dark areas.

Powered by high-performance OSRAM LEDs, the series offers three output levels to meet different lighting requirements. The 3.5-inch model delivers 2,630 effective lumens and reaches 1 lux at 220 meters, while the 5.5-inch model produces 5,280 effective lumens with a 1 lux distance of 335 meters. For maximum lighting performance, the 7-inch model delivers 7,500 effective lumens and reaches 1 lux at 510 meters.

Key Features

• Side Shooting Light Design – Designed to project light toward the sides as well as the forward area for improved overall visibility.
• Wide-Angle Illumination – Provides broader lighting coverage and helps reduce dark areas around the vehicle.
• Side-Emitting Lighting Technology – Optimized for applications where lateral illumination is important.
• OSRAM LEDs – High-performance LED technology delivers powerful and consistent illumination.
• Three Size Options – Available in 3.5-inch, 5.5-inch, and 7-inch models to suit different vehicle applications and lighting requirements.
• High Effective Lumens – Up to 7,500 effective lumens for demanding off-road lighting applications.
• Long-Range Performance – Up to 1 lux at 510 meters on the 7-inch model.
• Off-Road Applications – Suitable for trucks, SUVs, 4x4s, overland vehicles, utility vehicles, and other demanding environments.

Available Models & Specifications

3.5-Inch LED Side Shooting Light

The 3.5-inch LED Side Shooting Light is a compact solution for applications where additional side illumination is required without taking up excessive mounting space. Powered by OSRAM LEDs, it produces 2,630 effective lumens with 25W power and achieves 1 lux at 220 meters.

Its compact size makes it suitable for smaller off-road vehicles, auxiliary lighting positions, side-mounted applications, and custom vehicle builds where wide-angle illumination is required.

5.5-Inch LED Side Shooting Light

The 5.5-inch LED Side Shooting Light provides a balance between compact size and high-output performance. With 50W power, it delivers 5,280 effective lumens and achieves 1 lux at 335 meters.

The side-shooting design provides additional lateral illumination to improve visibility around the vehicle, making it well suited for trucks, SUVs, 4x4s, overland vehicles, and demanding off-road applications.

7-Inch LED Side Shooting Light

The 7-inch LED Side Shooting Light is the high-output option in the series, delivering 7,500 effective lumens from 75W power. It achieves 1 lux at 510 meters, providing strong illumination for demanding nighttime and off-road environments.

With its wide-angle side illumination, the 7-inch model can help expand the vehicle's overall lighting coverage and improve visibility around trails, obstacles, corners, and open off-road terrain.

Wide-Angle Side Illumination for Off-Road Driving

The key advantage of this LED Side Shooting Light series is its ability to provide illumination beyond the conventional forward-facing lighting area. The side-emitting design creates a wider lighting perspective, helping illuminate areas alongside the vehicle that can remain dark when using standard driving or spot beam lights.

This makes side shooting lights particularly useful for off-road trails, overlanding, rock crawling, forest roads, work vehicles, utility applications, and nighttime vehicle operations where broader lighting coverage is essential.

Applications

These LED Side Shooting Lights are suitable for:

• Off-road vehicles
• 4x4 trucks
• Pickup trucks
• SUVs
• Overland vehicles
• Utility vehicles
• Work vehicles
• Trail and adventure vehicles
• Side-mounted auxiliary lighting
• Wide-angle off-road lighting applications
